Circuit Board Assembly of Circuit Card Assembly
(click on thumbnail to enlarge)

At A and M Electronics, Inc., we hold numerous industry certifications and are uniquely experienced meeting the requirements of many demanding military and aerospace standards. We produced the circuit card assembly shown here, which was intended for use in extreme environmental conditions. Working with customer specifications, we sourced the components, including specialty adhesive and coating materials. Post assembly, we applied a conformal coating to the board to protect the sensitive electronics from moisture, dust, chemicals, and temperature extremes, which ensured zero-failure operation. Visual and automated optical inspections were executed in accordance with our ISO 9001:2015-certified quality management program. Our commitment to quality ensured that this component met all tolerance requirements as well as DOD-STD-1686, Class 2 standard for electrical discharge and MIL-STD-2000 for soldered electrical assemblies. Our personnel are certified to IPC-A-610 as well as ANSI/J-STD-001 All Classes.

In-depth knowledge and valued experience enable us to tackle projects of this complexity, providing fast turnarounds and reasonable costs for our customers. Contact us today to learn how we can improve your next circuit board assembly project.

Circuit Card Assembly Project Highlights

Circuit Card Assembly Capabilities Applied/Processes

Circuit Board Assembly
Component Sourcing

Conformal Coating

Tightest Tolerances

± 0.03″

Material Used

Adhesive, SN63/37 Solder

In process testing/inspection performed

100% Visual Inspection

A.O.I. (Automatic Optical Inspection)

Industry for Use



10-100 pieces

Delivery/Turnaround Time

2 Weeks (Standard) 1 Week available add 50%

Standards Met

Customer Specifications, 2D CAD Drawing
DOD-STD-1686, Class 2


Product Name

Circuit Card Assembly
